·Up to 5MP,3072×1728@30fps
·Color:0.0001lux@ (F1.6,AGC ON),B/W:0lux with IR
·S+265/H.265/H.264B/H.264M/H.264H/Motion JPEG
·Optical zoom 44X
·IR range up to 200m
·Support microSD/microSDHC/microSDXC card,up to 512GB
·Support smart surveillance, detect up to 32 faces at the same scene
·Support human/vehicle classification
·Operating conditions -40℃~70℃(-40℉~158℉), ≤95%RH
·AC24V±25%\DC24V±10%, PoE:IEEE 802.3bt IP66
Camera | |
Image Sensor | 1/1.8"CMOS |
Min. Illumination | Color:0.0001lux@ (F1.6,AGC ON),B/W:0lux with IR |
Shutter Time | 1s~1/100000s |
Day&Night | IR-cut filter with auto switch (ICR) |
Smart IR | Yes |
WDR | 120dB |
S/N | 40.6dB |
Lens | |
Focal Length | 6mm～264mm |
Optical Zoom | 44X |
Digital Zoom | 16X |
Zoom Speed | <5s |
Aperture Range | F1.6~F5.3 |
Aperture Type | Auto(P-Iris) |
Field of View | 59.2~2.5°(H); 34.6°~1.4°(V); 66.7~2.9°(D) |
Focus Control | Auto/Semi-auto/Manual |
Close Focus Distance | 100mm~1000mm |
DORI Distance | Detect:2414m Observe:958m Recognize:483m Identify:241m |
Pan&Tilt | |
Pan Range | 0~360°(P) |
Pan Speed | Manual Speed:0.1°～180°/s Preset Speed:240°/s |
Tilt Range | -16°~90°(T) (Default -3°~90°(T)) |
Tilt Speed | Manual Speed:0.1°～120°/s Preset:180°/s |
3D Position | Yes |
Preset | 500 |
Cruise | 16(up to 32 presets per cruise) |
Scan | 8 |
Pattern | 8,each with 600s memory or 1000 orders |
Scheduled Task | Preset,Cruise,Scan,Pattern |
North Point | Yes(Manual setting) |
Power-off Memory | Yes |
Preset Freezing | Yes |
Illuminator | |
IR LEDs | 10 |
IR Distance | Up to 200m |
Wavelength | 850nm |
IR Irradiation Angle | Yes |
White LEDs | 4 |
Whitelight Distance | 50m |
Compression Standard | |
Video Compression | S+265/H.265/H.264B/H.264M/H.264H/Motion JPEG |
Video Bit Rate | 32Kbps~16Mbps |
Audio Compression | G.711A/G.711U/ADPCM_D/AAC_LC |
Audio Sampling Rate | 8KHz/32KHz/48KHz |
Image | |
Max. Resolution | 5MP,3072×1728@30fps |
Main Stream | PAL:25fps(3072×1728,2688×1520,2560×1440,2304×1296,1920×1080,1280×960,1280×720),50fps（1920×1080,1280×960,1280×720) NTSC:30fps(3072×1728,2688×1520,2560×1440,2304×1296,1920×1080,1280×960,1280×720),60fps(1920×1080,1280×960,1280×720) |
Sub Stream | PAL:25fps(704×576,704×288,640×360,352×288) NTSC:30fps(704×480,704×240,640×360,352×240) |
Third Stream | PAL:25fps(1920×1080,1280×720,704×576,640×360,704×288,352×288) NTSC:30fps(1920×1080,1280×720,704×480,640×360,704×240,352×240) |
BLC | Yes |
HLC | Yes |
AGC | Yes |
3DNR | Yes |
White Balance | Auto/Semi-Auto/Manual/Sunshine/Nature Light/Warmlight Lamp/Daylight Lamp/Filament Lamp/Lock White Balance |
ROI | 7 rectangular 3D fixed focus areas,supporting 1 rectangular dynamic tracking ROI |
EIS | Yes |
OSD | 5 regions(Each region can have a maximum of 127 characters,up to 5 lines); 16*16/24*24/32*32/48*48/64*64/96*96/adaptable size; Vector/Lattice |
Defog | Yes |
Flip | Normal/Horizontal Mirror/Vertical Mirror/Inverted Flip |
Regional Exposure | Yes |
Regional Focus | Yes |
Demist | Yes |
Privacy Mask | 24 regions(Up to 4 blocks in the same scene) |
Feature | |
General Alarm | Motion Detection; Mask Alarm; Alarm Input |
Exceptions Alarm | Disk Full; Disk R/W Error; Recording Exception; IP Address Conflict; MAC Address Conflict; FTP Server Exception ; Network cable disconnected |
Linkage Method | Send Email; Trigger Sound; Trigger Warmlight; Trigger Recording; Trigger Capture; Notify Surveillance Center; Alarm Output |
Video Analytics | Human/Vehicle Classification; Tripwire; Double Tripwire; Perimeter; Object Abandon; Object Missing; Heatmap; Loitering; Running; Parking; People Counting; Safety Helmet Detection; On Duty Detection; Video Abnormal; Audio Abnormal; Crowed Detection |
Auto Early Warning(AEW) | Yes |
Auto-Tracking | Yes |
Face Mode | Face Capture |
Face Capture Performance | Best Face Size 60 Pixels; Minimum face size 19 Pixels; Best facial capture distance ≤100m; Detect up to 32 faces at the same scene; Capture up to 16 faces at the same scene; Capture rate ≥99%(continuous scene with 10 people or less); Gender 85%,age (±5) 85%,mask 90%,glasses 85%,beard 80% (Less than 10 people in view) |
Network | |
ANR | Yes |
Protocols | HTTP; HTTPS; UDP; UPnP; ICMP; IGMP; SNMP v1\v2\v3; DHCP; DNS; DDNS; Easy DDNS; NTP; SMTP; TLS v1.2; SSL; 802.1x; QoS; IPv4; IPv6; PPPoE; SSH; Unicast; Multicast; ARP; RTP; SRTP; FTP; SFTP; RTSP; TCP; SMB; CIFS |
System Compatibility | P2P; ONVIF(Profile S/T/G/M); SDK; CGI; Milestone; RTSP; RTMP; RTMP; HTTP PUSH |
Remote Connection | ≤7 |
User/Host | 32users, Level 4:Admin/Browse/Browse+Control/Browse+Control+Set |
Client | Easy7 VMS |
Moblie Client | EasyLive Plus |
Web | IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+ |
Interface | |
Communication Interface | 1×RJ45 (10/100Base-T) |
Audio I/O | 1×input, two-core , max. input amplitude:3.3 Vpp, input impedance:1 KΩ, interface type:non-equilibrium; 1×output, two-core, max. output amplitude:3.3 Vpp, output impedance:100 Ω, interface type: non-equilibrium |
Alarm I/O | 8×input,TTL,3mA,3.3VDC; 2×relay output,1A,24VDC |
Built-in Speaker | 1×Built-in Loudspeaker, 4Ω4W |
Reset Button | Yes |
On-board Storage | Support microSD/microSDHC/microSDXC card,up to 512GB |
Additional Interfaces | RS-485 |
Wiper | Yes |
General | |
Web Client Language | 19 languages Simple Chinese/English/Traditional Chinese/Spanish/Italian/Korean/Turkish/Russian/Thai/Polish/French/Dutch/Hebraism/Vietnamese/Arabic/German/Ukrainian /Portuguese/Albanian |
Operating Temperature | -40℃~70℃(-40℉~158℉) |
Operating Humidity | ≤95%RH |
Storage Temperature | -40℃~70℃(-40℉~158℉) |
Storage Humidity | 10%~95%RH(non-condensing) |
Power Supply | AC24V±25%\DC24V±10%; PoE:IEEE 802.3bt |
Power Consumption | 13.4W; 45W |
Protection | Surge4000V; ESD6000V; IP66 |
Material | Metal |
Boundary Dimensions | 222(D)372(H)mm |
Package Dimensions | 320(L)320(W)520(H)mm |
GrossWeight | 8.95kg |
NetWeight | 5.3Kg |
